1pc Upgraded Adjustable DC Motor Speed PWM Controller 10V 12V 24V 30V Reversing Switch 120W
1pc Upgraded Adjustable DC Motor Speed PWM Controller 10V 12V 24V 30V Reversing Switch 120W
Couldn't load pickup availability
SPECIFICATIONS
Application: Computer
Brand Name: AOKIN
Choice: yes
Condition: New
Dissipation Power: 120W
High-concerned chemical: None
Operating Temperature: 1pc Upgraded Adjustable DC Motor Speed PWM Controller
Origin: Mainland China
Package: SOP
Supply Voltage: 10v 12v 24V 30V
Type: buck (stepdown) regulator
is_customized: Yes
Working Voltage: DC 10V - DC 30V
Maximum power: 120W
Rated Current: 3A
Max Current: 4A
Maximum continuous output current:3A ;Overload short circuit protection current:4A ,short circuit time does not exceed 30 seconds
PWM Frequency: 500 KHz
PWM pulse width modulation range: 5% -95%
Motor Type:Brush
Control power: 12V*3A= 3 6W, 24V*3A= 72W, more than 24A maximum 120W
Potentiometer: resistance value B10K; wire length 20 cm; opening 8mm;
The output voltage is approximately：0-100% of the input voltage.
Pls do not connect AC power directly(Such as:110V AC),the input volt of this controller should be DC,otherwise it will be burned out
Positive and negative pole of the POWER can not be reversed
Positive and negative pole of the MOTOR can be reversed.When the direction of operation is inconsistent with your expectations,you can change the direction by adjusting the order of the line
Adjust the potentiometer knob to change output duty cycle
