3S/4S/5S BMS 12V 100A Li-ion LMO Ternary Lithium Battery Protection Circuit Board Li-Polymer Balance Charging Module
3S/4S/5S BMS 12V 100A Li-ion LMO Ternary Lithium Battery Protection Circuit Board Li-Polymer Balance Charging Module
Couldn't load pickup availability
SPECIFICATIONS
Application: Electric Toy
Brand Name: other
Choice: yes
Condition: New
Dissipation Power: 100A
Model Number: 3S/4S/5S BMS 12V 100A Li-ion LMO Ternary Lithium Battery Protection
Origin: Mainland China
Package: SOP
Supply Voltage: 12V/21V
Type: Voltage Regulator
is_customized: Yes
• High Capacity Battery :This product features a high-capacity 100a li-ion battery, providing long-lasting power for your electric toy.
• Integrated Circuits :As an integrated circuits product, it ensures efficient and effective operation, enhancing the performance of your device.
• Voltage Regulator :The voltage regulator feature ensures optimal voltage output, protecting the battery from overcharging or undercharging.
• Li-Polymer Balance Charging Module :The li-polymer balance charging module ensures the battery is charged evenly, prolonging its lifespan and ensuring optimal performance.
• Origin : Mainland China
• Versatile Application :Ideal for electric toys, this product can be used in a variety of applications, making it a versatile choice for your power needs.
3S/4S/5S BMS 12v 100a Li-ion LMO ternary lithium battery protection circuit board Li-Polymer balance charging module
Features:
• High quality 18650 battery charging Module
• BMS 100a LMO ternary lithium battery protection circuit board Li-Polymer balance charging module battery overcharge protection circuit
• Single cell battery overcharge protect voltage : 4.21-4.29 V
• Single cell battery overcharge protect recover voltage : 4.14-4.24V
• Overcharge protect Current : 100A
Specification:
100% brand new and high quality 18650 battery charging module
FOR Lithium POLYMER protection Board(3.7V)
Single cell battery overcharge protect voltage : 4.21-4.29 V
Single cell battery overcharge protect recover voltage : 4.14-4.24V
Overcharge protect delay : 1.5-2.5S
Single cell battery over-discharge protect voltage : 2.72-2.88 V
Overcharge protect Current : 100A
Over-discharge protect Current : 100A
Over-discharge protect delay : 0.5-1.5S
Temperature protect : Yes
Disconnect protect : Yes
Shortage protect : Yes
Shortage delay : 100-600 uS
Shortage protect recover : YES
Charging Current : 60A
Current Balance : Yes
Ampere balance (Current) : 60MA
Voltage alance accuracy : 4.14-4.24V
Package include :
• 1 x3S/4S/5S BMS 12V 100A Li-ion LMO Ternary Lithium Battery Protection Circuit Board
1. Key away from Fire
2. Due to includeing small parts, please keep away from Children under Three.
3. Please leave 5 star feedback if you're satisfied with our products and service, we will appreciate it
4. If the products you received was damaged or any more question, please feel free to contact us.
